operations_research::math_opt::LinearConstraint Class Reference

#include <linear_constraint.h>

Public Types
using	IdType = LinearConstraintId
	The typed integer used for ids.

Public Member Functions
	LinearConstraint (const ModelStorage *storage, LinearConstraintId id)
int64_t	id () const
LinearConstraintId	typed_id () const
const ModelStorage *	storage () const
double	lower_bound () const
double	upper_bound () const
absl::string_view	name () const
bool	is_coefficient_nonzero (Variable variable) const
double	coefficient (Variable variable) const
	Returns 0.0 if the variable is not used in the constraint.
BoundedLinearExpression	AsBoundedLinearExpression () const
std::string	ToString () const

Friends
bool	operator== (const LinearConstraint &lhs, const LinearConstraint &rhs)
bool	operator!= (const LinearConstraint &lhs, const LinearConstraint &rhs)
template<typename H >
H	AbslHashValue (H h, const LinearConstraint &linear_constraint)
std::ostream &	operator<< (std::ostream &ostr, const LinearConstraint &linear_constraint)

Detailed Description

A value type that references a linear constraint from ModelStorage. Usually this type is passed by copy.

This type implements https://abseil.io/docs/cpp/guides/hash.

Definition at line 43 of file linear_constraint.h.

Member Typedef Documentation

IdType

using operations_research::math_opt::LinearConstraint::IdType = LinearConstraintId

The typed integer used for ids.

Definition at line 46 of file linear_constraint.h.

Constructor & Destructor Documentation

LinearConstraint()

operations_research::math_opt::LinearConstraint::LinearConstraint ( const ModelStorage * storage, LinearConstraintId id )

inline

Definition at line 189 of file linear_constraint.h.

Member Function Documentation

AsBoundedLinearExpression()

BoundedLinearExpression operations_research::math_opt::LinearConstraint::AsBoundedLinearExpression ( ) const

inline

Returns the constraints as a bounded linear expression.

The linear expression will have a zero offset, even if the constraint was created with a non-zero one. For example:

const LinearConstraint c = model.AddLinearConstraint(3.2 <= x + 1.0 <= 4.2);

///< Here e will contain 3.2 - 1.0 <= x <= 4.2 - 1.0. const BoundedLinearExpression e = c.AsBoundedLinearExpression();

Definition at line 142 of file linear_constraint.h.

coefficient()

double operations_research::math_opt::LinearConstraint::coefficient ( Variable variable ) const

inline

Returns 0.0 if the variable is not used in the constraint.

Definition at line 136 of file linear_constraint.h.

id()

int64_t operations_research::math_opt::LinearConstraint::id ( ) const

inline

Inline function implementations

Definition at line 108 of file linear_constraint.h.

is_coefficient_nonzero()

bool operations_research::math_opt::LinearConstraint::is_coefficient_nonzero ( Variable variable ) const

inline

Definition at line 129 of file linear_constraint.h.

lower_bound()

double operations_research::math_opt::LinearConstraint::lower_bound ( ) const

inline

Definition at line 114 of file linear_constraint.h.

name()

absl::string_view operations_research::math_opt::LinearConstraint::name ( ) const

inline

Definition at line 122 of file linear_constraint.h.

storage()

const ModelStorage * operations_research::math_opt::LinearConstraint::storage ( ) const

inline

Definition at line 112 of file linear_constraint.h.

ToString()

std::string operations_research::math_opt::LinearConstraint::ToString ( ) const

inline

Returns a detailed string description of the contents of the constraint (not its name, use << for that instead).

Definition at line 154 of file linear_constraint.h.

typed_id()

LinearConstraintId operations_research::math_opt::LinearConstraint::typed_id ( ) const

inline

Definition at line 110 of file linear_constraint.h.

upper_bound()

double operations_research::math_opt::LinearConstraint::upper_bound ( ) const

inline

Definition at line 118 of file linear_constraint.h.

Friends And Related Symbol Documentation

AbslHashValue

template<typename H >

H AbslHashValue ( H h, const LinearConstraint & linear_constraint )

friend

Definition at line 172 of file linear_constraint.h.

operator!=

bool operator!= ( const LinearConstraint & lhs, const LinearConstraint & rhs )

friend

Definition at line 167 of file linear_constraint.h.

operator<<

std::ostream & operator<< ( std::ostream & ostr, const LinearConstraint & linear_constraint )

friend

Streams the name of the constraint, as registered upon constraint creation, or a short default if none was provided.

Todo

(b/170992529): handle quoting of invalid characters in the name.

Definition at line 177 of file linear_constraint.h.

operator==

bool operator== ( const LinearConstraint & lhs, const LinearConstraint & rhs )

friend

Definition at line 163 of file linear_constraint.h.

---

The documentation for this class was generated from the following file:

• ortools/math_opt/cpp/linear_constraint.h
